Acut Digital 200A Plasma Cutting Machine
10000.00 - 3000000.00 INR/Piece
Product Details:
- Type Plasma Cutter
- Material steel, copper, aluminum
- Computerized No
- Automatic Grade Semi-Automatic
- Control System Human Machine Interface
- Cutting Thickness 55 Millimeter (mm)
- Cutting Function Semi Automatic
- Click to View more
X
Acut Digital 200A Plasma Cutting Machine Price And Quantity
- 1 Piece
- 10000.00 - 3000000.00 INR/Piece
Acut Digital 200A Plasma Cutting Machine Product Specifications
- Semi Automatic
- steel, copper, aluminum
- Human Machine Interface
- 58/128 Kilograms (kg)
- 55 Millimeter (mm)
- No
- 1 year
- Yellow
- Water Cooling
- Plasma Cutter
- Semi-Automatic
Acut Digital 200A Plasma Cutting Machine Trade Information
- 100 Piece Per Day
- 02 Days
- Maharashtra
Product Description
1) Inverter technology provides a low weight power source that can be easily maintained or carried by a welder2) ACUT series is a water cooled power source to provide nonstop work with 100% duty cycle with full power
3) ACUT series is provides cutting steel, stainless steel, copper, aluminum, etc.
4) Self-diagnostic and different protections help in work and maintain power source
Specification
| Model | ACUT200 |
| Rated input voltage /frequency(Hz) | 3 Phase ,380V+/-10% 50/60Hz |
| Rated input capacity (KVA) | 42.8 |
| Rated input current (A) | 65.0 |
| Duty Cycle (40 C) | 100%-200A |
| OCV (V) | 350 |
| Output current range (A) | 30-200 |
| Arc ignition method | Special HF |
| Maximum cutting thickness (mm) | 55 |
| Clean cut thickness (mm) | 1-20 |
| Air pressure (MPa) | 0.40.55 |
| Water flow rate (L/min) | 1.4 |
| Protection class | IP23 |
| Insulation class | H |
| Dimension (mm) | 635x399x542 |
| Weight (kg/lb) | 58/128.1 |
We Are Mainly Dealing In Maharashtra
